The Audi A5 LED emblem replaces the factory front grille badge on the A5, S5, and RS5 with a dynamic illuminated version featuring four animation effects that activate every time you lock, unlock, or start the car.
This product fits all A5 body styles — Coupe, Sportback, and Cabriolet — across the B8 (2008–2019) and B9 (2020–2024) platforms, including S5 and RS5 variants.
The four-ring Audi logo glows in pure white LED — crisp and clean, matching the A5’s distinctive design character, whether your car has the original B8 styling or the sharper B9 facelift.
Audi A5 LED Emblem Key Features
- 4 dynamic animation effects — outside-in sweep, up-and-down motion, chain-link effect, and pulsing on/off flash. Activates automatically on lock, unlock, and ignition start. No app required.
- Fits A5, S5, and RS5 — Coupe, Sportback, and Cabriolet across B8 (2008–2019) and B9 (2020–2024) platforms.
- Chrome OEM-matched finish — chrome-plated surface matches the factory A5 badge exactly in size and finish. No visible white border or protruding edge when unlit.
- Pure white LED output — clean white illumination matching factory LED headlight colour temperature. No yellow tint.
- Waterproof 2nd-gen housing — enhanced waterproofing rated for 10,000+ hours working life.
- Two-wire 12V connection — connects to headlight or DRL circuit. No VCDS, no OBD adapter, no dealer visit required.
- 1-year full warranty — covers LED failure, housing seal failure, and connector faults.
Compatibility — Audi A5 LED Emblem by Model & Year
A5/S5 B8 Platform — Select “A5/S5 2008–2019” variant:
Audi A5 Coupe B8 (2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016)
Audi A5 Sportback B8 (2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016)
Audi A5 Cabriolet B8 (2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016)
Audi S5 Coupe B8 (2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016)
Audi S5 Sportback B8 (2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016)
Audi S5 Cabriolet B8 (2010, 2011, 2012, 2013, 2014, 2015, 2016)
Audi RS5 Coupe B8 (2012, 2013, 2014, 2015)
Audi RS5 Cabriolet B8 (2013, 2014, 2015)
Audi A5 Coupe B9 (2017, 2018, 2019) — Pre-facelift
Audi A5 Sportback B9 (2017, 2018, 2019) — Pre-facelift
Audi S5 Coupe B9 (2017, 2018, 2019) — Pre-facelift
Audi S5 Sportback B9 (2017, 2018, 2019) — Pre-facelift
Audi RS5 Coupe B9 (2018, 2019) — Pre-facelift
Audi RS5 Sportback B9 (2018, 2019) — Pre-facelift
A5/S5 B9 Facelift Platform — Select “A5/S5 2020–2024” variant:
Audi A5 Coupe B9 Facelift (2020, 2021, 2022, 2023, 2024)
Audi A5 Sportback B9 Facelift (2020, 2021, 2022, 2023, 2024)
Audi A5 Cabriolet B9 Facelift (2020, 2021, 2022, 2023, 2024)
Audi S5 Coupe B9 Facelift (2020, 2021, 2022, 2023, 2024)
Audi S5 Sportback B9 Facelift (2020, 2021, 2022, 2023, 2024)
Audi RS5 Coupe B9 Facelift (2020, 2021, 2022, 2023, 2024)
Audi RS5 Sportback B9 Facelift (2020, 2021, 2022, 2023, 2024)
To confirm which variant applies to your car, check your build year on your registration document.
If your A5/S5/RS5 was built between 2008 and 2019, select the “A5/S5 2008–2019” variant.
If built between 2020 and 2024, select the “A5/S5 2020–2024” variant.
If you are unsure, contact our team with your model, body style, and year and we will confirm before you order.
Technical Specifications
- Compatible models: Audi A5, S5, RS5 — Coupe, Sportback, Cabriolet (2008–2024)
- LED colour: Pure white
- Colour options: Silver chrome / Gloss black chrome
- Power supply: DC 12V (±10%)
- Power consumption: 2W
- Operating voltage: 13V maximum — do not exceed
- Current draw: 0.1A
- Wire length: 0.6m
- Package contents: 1x Audi A5 LED emblem, wiring harness, 3M adhesive tape
Wiring Guide
Red wire (positive): Connect to the DRL circuit, headlight circuit, or taillight circuit.
Do not connect to the brake light circuit — brake light voltage spikes will damage the emblem.
Black wire (negative/earth): Connect to any body earth point in the engine bay.
Night-only mode: Wire red to the headlight positive → emblem activates with headlights only.
Always-on mode: Wire red to the DRL or taillight positive → emblem activates whenever the ignition is on.
Frequently Asked Questions — Audi A5 LED Emblem
Does this fit the Audi A5 Sportback? +
Yes.
The A5 Sportback B8 (2009–2019) and B9 (2017–2024) uses the same front grille badge as the A5 Coupe and Cabriolet across all years.
Select the variant matching your build year — “A5/S5 2008–2019” for pre-2020 Sportbacks, and “A5/S5 2020–2024” for the B9 Facelift Sportback.
Does this fit the Audi RS5? +
Yes.
The RS5 B8 Coupe (2012–2015), RS5 B8 Cabriolet (2013–2015), RS5 B9 Coupe (2018–2024), and RS5 B9 Sportback (2018–2024) all use the same front badge as the standard A5.
Select “A5/S5 2008–2019” for RS5 B8 and pre-facelift B9 models, and “A5/S5 2020–2024” for the B9 Facelift RS5.
The Gloss Black finish is particularly popular among RS5 owners.
Does this fit the Audi A5 Cabriolet? +
Yes.
The A5 Cabriolet B8 (2009–2016) and A5 Cabriolet B9 Facelift (2020–2024) use the same front grille badge as the Coupe and Sportback variants.
Select the correct variant based on your build year.
Which variant do I select — 2008–2019 or 2020–2024? +
Check your car’s build year on your registration document or V5C.
Select “A5/S5 2008–2019” for all A5, S5, and RS5 models built between 2008 and 2019.
Select “A5/S5 2020–2024” for all A5, S5, and RS5 models built between 2020 and 2024.
Both variants are priced at $149.99.
Silver or Black — which finish suits the A5, S5, or RS5 best? +
Silver chrome matches the factory badge finish exactly and looks completely OEM when unlit — the most popular choice for A5 Coupe and Cabriolet owners.
Gloss black is the most popular choice for S5 and RS5 owners, particularly those with a Black Edition, Competition, or S-line Black specification.
Both produce identical pure white illumination when active.
Does the Audi A5 LED emblem require any coding? +
No.
The emblem connects to the standard 12V headlight or DRL circuit using two wires.
No VCDS, no OBD adapter, no module changes, and no dealer visit are required at any point.
The installation is fully reversible — the factory badge can be refitted at any time.
Is the Audi A5 LED emblem waterproof? +
Yes.
The 2nd-generation sealed housing is fully dustproof and waterproof, rated safe for rain, road spray, and standard car washing including automatic and hand washing at normal pressure distances.
Rated for 10,000+ hours of working life.
Will fitting this emblem void my Audi A5 warranty? +
In most cases no.
The installation leaves all factory wiring completely intact, requires no ECU or module changes, and is fully reversible.
The factory badge can be refitted at any time.
Retain your original badge and proof of purchase for complete peace of mind.
Still have a question? Contact our support team — we reply within 24 hours.
