The Audi A7 LED emblem replaces the factory front grille badge on the A7, S7, and RS7 Sportback with a dynamic illuminated version featuring four animation effects that activate every time you lock, unlock, or start the car.
Available for both the C7 (2012–2018) and C8 (2019–2024) platform generations, this single product covers all three performance variants of the A7 range — standard A7, S7, and RS7 — across all body configurations.
⚠ ACC / Radar Compatibility Notice: Audi A7 C8 models (2019–2024) equipped with Adaptive Cruise Control may have the front radar sensor positioned directly behind the grille badge.
Fitting an LED emblem over an ACC radar sensor may reduce detection range or trigger dashboard warnings.
Before ordering a C8 A7/S7/RS7, check whether your car has a radar sensor behind the front badge — if it does, contact our team with your VIN and we will confirm compatibility.
The C7 A7 (2012–2018) does not typically have a front grille-mounted radar sensor and is fully compatible.
Audi A7 LED Emblem Key Features:
- 4 dynamic animation effects — outside-in sweep, up-and-down motion, chain-link effect, and pulsing on/off flash. Activates automatically on lock, unlock, and ignition start. No app required.
- Fits A7, S7, and RS7 — Sportback across C7 (2012–2018) and C8 (2019–2024) platforms.
- Chrome OEM-matched finish — chrome-plated surface matches the factory A7/S7/RS7 badge exactly in size and finish. No visible white border or protruding edge when unlit.
- Pure white LED output — clean white illumination matching factory LED headlight colour temperature. No yellow tint.
- Waterproof 2nd-gen housing — enhanced waterproofing rated for 10,000+ hours working life.
- Two-wire 12V connection — connects to headlight or DRL circuit. No VCDS, no OBD adapter, no dealer visit required.
- 1-year full warranty — covers LED failure, housing seal failure, and connector faults.
Compatibility — Audi A7 S7 RS7 LED Emblem by Generation
C7 Platform — Select “A7 2012–2018” variant:
Audi A7 Sportback C7 (2012, 2013, 2014, 2015, 2016, 2017, 2018)
Audi S7 Sportback C7 (2012, 2013, 2014, 2015, 2016, 2017, 2018)
Audi RS7 Sportback C7 (2013, 2014, 2015, 2016, 2017, 2018)
C8 Platform — Select “A7 2019–2024” variant:
Audi A7 Sportback C8 (2019, 2020, 2021, 2022, 2023, 2024)
Audi S7 Sportback C8 (2020, 2021, 2022, 2023, 2024)
Audi RS7 Sportback C8 (2020, 2021, 2022, 2023, 2024)
To confirm your generation, check your build year on your registration document.
If built between 2012 and 2018, select the “A7 2012–2018” variant.
If built between 2019 and 2024, select the “A7 2019–2024” variant.
If you are unsure, contact our team with your model, variant, and year and we will confirm before you order.
Technical Specifications
- Compatible models: Audi A7, S7, RS7 Sportback C7 (2012–2018) and C8 (2019–2024)
- LED colour: Pure white
- Colour options: Silver chrome / Gloss black chrome
- Power supply: DC 12V (±10%)
- Power consumption: 2W
- Operating voltage: 13V maximum — do not exceed
- Current draw: 0.1A
- Wire length: 0.6m
- Package contents: 1x Audi A7 LED emblem, wiring harness, 3M adhesive tape, installation instructions
Wiring Guide
Red wire (positive): Connect to the DRL circuit, headlight circuit, or taillight circuit.
Do not connect to the brake light circuit — brake light voltage spikes will damage the emblem.
Black wire (negative/earth): Connect to any body earth point in the engine bay.
Night-only mode: Wire red to the headlight positive → emblem activates with headlights only.
Always-on mode: Wire red to the DRL or taillight positive → emblem activates whenever the ignition is on.
Frequently Asked Questions — Audi A7 S7 RS7 LED Emblem
Does this fit the Audi RS7 Sportback? +
Yes.
The RS7 Sportback C7 (2013–2018) and RS7 Sportback C8 (2020–2024) both use the same front grille badge as the standard A7 and S7.
Select “A7 2012–2018” for the C7 RS7 and “A7 2019–2024” for the C8 RS7.
Note: check whether your C8 RS7 has an ACC radar sensor behind the front grille badge before ordering.
Does this fit the Audi S7 Sportback? +
Yes.
The S7 Sportback C7 (2012–2018) and S7 Sportback C8 (2020–2024) use the same front grille badge as the A7.
Select the variant matching your build year and choose your preferred colour.
Gloss black is particularly popular for S7 and RS7 owners with dark exterior styling.
Does the C8 A7/RS7 work with Adaptive Cruise Control? +
The C7 A7 (2012–2018) does not typically have an ACC radar sensor behind the front grille badge and is fully compatible with this emblem.
The C8 A7, S7, and RS7 (2019–2024) may have a front radar sensor behind the grille badge depending on specification.
If your C8 model has ACC, check whether the sensor is behind the front emblem before ordering.
Contact our team with your VIN if you are unsure — we will confirm compatibility before you purchase.
Which variant do I select — 2012–2018 or 2019–2024? +
Check your build year on your registration document or V5C.
Select “A7 2012–2018” for all A7, S7, and RS7 models built between 2012 and 2018.
Select “A7 2019–2024” for all A7, S7, and RS7 models built between 2019 and 2024.
Both variants are priced at $149.99.
Silver or Black — which finish suits the A7, S7, or RS7 best? +
Silver chrome matches the factory badge finish exactly and looks completely OEM when unlit — the most popular choice for standard A7 owners who prefer a subtle premium upgrade.
Gloss black is the more popular choice for S7 and RS7 owners, particularly those with a Black Edition, Competition, or Carbon Edition specification with dark exterior trim.
Both produce identical pure white illumination when active.
Does the Audi A7 LED emblem require any coding? +
No.
The emblem connects to the standard 12V headlight or DRL circuit using two wires.
No VCDS, no OBD adapter, no module changes, and no dealer visit are required at any point.
The installation is fully reversible — the factory badge can be refitted at any time.
Is the Audi A7 LED emblem waterproof? +
Yes.
The 2nd-generation sealed housing is fully dustproof and waterproof, rated safe for rain, road spray, and standard car washing including automatic and hand washing at normal pressure distances.
Rated for 10,000+ hours of working life.
Will fitting this emblem void my Audi A7 warranty? +
In most cases no.
The installation leaves all factory wiring completely intact, requires no ECU or module changes, and is fully reversible.
The factory badge can be refitted at any time.
Retain your original badge and proof of purchase for complete peace of mind.
Still have a question? Contact our support team — we reply within 24 hours.
